Model BPM|Flow processes

You can create and model BPM|Flow processes in the model overview via the separate Apps | BPM|Flow processes area:

BPM|Flow processes in the Apps area

Special features of the modeling of BPM|Flow processes

To successfully transfer a process from Aeneis to BPM|Flow, you must model it as follows:

Note that the display name in the swimlanes corresponds to the users or groups of your BPM|Flow system.
For each event, activity or gateway, specify by assignment who is responsible for its execution.
Assign an Owner, Starter, and Deployer at the start event.
Define to which activity the respective events belong.
For gateways, model the Yes path first and then the No path.
Close loops again on parallel activities.
Model at least one start event and one end event.
Do not use special characters for gateways.

See also: How processes are generally created and modeled in WebModeller is described in the documentations Create model objects and BPMN diagrams.

See also: For the transfer of Aeneis into the BPM|Flow system you have to parameterize your BPM|Flow process additionally. For all information on the topic, see Parameterize BPM|Flow processes.
